LTspice Tutorial for Beginners - Let's Simulate Electronics! (Udemy.com)

A Complete Guide from A to Z

( 42 Reviews )

Created by: Ye Zhao, PhD

Produced in 2021

What you will learn

Time-domain Simulation: Transient simulation (.Tran), Initial conditions (.IC), Parameter sweep (.step),
Measure (.meas), Piecewise Linear Functions (PWL) for voltage source, Arbitrary behavioral voltage (.bv)
DC operating point (.op), DC sweep (.dc), temperature (.temp), and DC transfer function (.tf)
Frequency-domain Analysis: Fourier Theorem and Bode Plot, Small-signal transfer function
Laplace transform, AC analysis (.AC), Laplace transform by Voltage Dependent Source
Netlist and SPICE syntax
Import Third-Party Models, Sub-circuit, and Hierarchy
Worst-case Analysis: Probability distribution in LTspice, Monte Carlo, Worst-case analysis

Quality Score

Content Quality

Video Quality

Qualified Instructor

Course Pace

Course Depth & Coverage

Overall Score : 92 / 100

Course Description

Updates: On 05/09/2021: The zip file of all source files is updated to include two more missing LTspice files. Thanks to RobertOn 05/04/2021: Video and Lecture notes of "Fourier Theorem and Bode Plot" is updated to correct a typo. Thanks to KrisOn 05/04/2021:
Lecture note of "types of dc sweep" is updated to correct a few typos. Thanks to Kris for pointing it outOn 04/15/2021: Fourier Theorem and Bode Plot_update.
pdf has been uploaded to correct some reference links on the slidesOn 03/03/2021: Videos are available in 1080p resolution.
On 03/03/2021: A typo in DC transfer function (.
tf) slides is fixed. Thanks to Zhengzhong Zhao for pointing it outOn 01/07/2021: A new lecture about "Display op in transient simulation" is createdOn 12/03/2019: The voltage pulse setup is updated according to the latest LTspice requirement:
Lec 6 - Transient simulation (.
Tran)On 08/31/2019: A typo is corrected in both video and slides: Lec 17 - Small-signal transfer function and Laplace transform.
LTspice source files: "Download_LTspice Beginner_2021-05-09.
zip"~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~LTspice tutorial that covers the most commonly used functions: such as transient, AC analysis, dc transfer functions, Laplace transform, sub-circuit, worst-case analysis, and moreWell-prepared and self-explanatory slides in PDF are downloadable. Use it as good reference for your daily work.
LTspice source files are downloadable. Run and see results in seconds.
All materials are based on the windows PC! Sorry Mac OS users!!
Who this course is for:
Anyone who is interested in LTspiceCollege students in electrical engineeringElectrical engineers at all levelsWho really want to put "LTspice" in Resume

Time: 4h

Instructor Details

Ye Zhao, PhD

4.6 Rating
42 Reviews

11/2017 Current: Founder of EEsanity
04/2019 Current: Principal Electrical Engineer, Analogic Corporation, Canton, MA USA
12/2017 04/2019: Senior Design Engineer, Murata Power Solutions, Westborough, MA USA
05/2015 11/2017: Senior Power Electronics Engineer, Yaskawa-Solectria Solar, Lawrence, MA, USA
06/2005 07/2008: Sales/Tech Support Engineer, ABB High Voltage Switchgear Co., Ltd., Beijing, China
Master (2011) and PhD (2015) from Northeastern University, Boston, MA, USA
Bachelor (2005) in Electrical Engineering from Beijing Jiaotong University, Beijing, China
